Pallet Flow Racking

Pallet Flow Rack, also known as roller pallet racking, is a high-density industrial storage system that utilizes gravity rollers (rulo) to facilitate pallet movement. This racking system is widely recognized as one of the most efficient and safest warehouse storage solutions available today, ensuring high storage density and optimized material flow.

Pallet Flow Rack, also known as roller pallet racking, is a high-density storage system that utilizes rollers to move pallets efficiently. With its unique design, this system minimizes forklift contact with racking structures, making it one of the safest and most space-efficient warehouse storage solutions available today. To determine the best racking system for your warehouse, let Eurorack guide you through the key features and benefits of Pallet Flow Racking.

Learn about what is Pallet Flow Racking?​

• Average Load Capacity: 1,000 kg per pallet (adjustable based on storage needs)
• Maximum Height: Up to 10 meters
• Omega-Shaped Load-Bearing Uprights for enhanced stability
• Flow Rack Surface: Assembled with high-quality steel rollers and rails, meeting European standards
• Material: Made from electrostatically powder-coated steel
• Standard Colors: Blue - Orange - Gray (customizable upon request)

The Pallet Flow Rack System consists of five key components, ensuring high load capacity and smooth pallet movement:

• Omega-Shaped Upright Frame: Primary load-bearing structure supporting the entire racking system.
• Frame Bracing: Distributes load evenly between the upright frames, enhancing stability.
• Beam: Connects two upright frames and serves as the primary support for pallets.
• Support Bar: Reinforces the beams to keep pallets securely in place.
• Roller System: Enables smooth pallet movement while ensuring safety and operational efficiency.

* Important Note: All components are modular and assembled using bolts and screws, allowing for flexibility in installation, easy adjustments, and reconfiguration when needed.

Steel roller systems are used to install Pallet Flow Racking

• Optimizes Over 70% of Warehouse Floor Space, accommodating up to 20 pallets in depth.
• High-Capacity Storage, supporting heavy-duty loads up to 3,000 kg per level.
• Fast & Efficient Loading/Unloading with a pallet conveyor system.
• Maximum Safety ensured by speed control devices.
• Minimizes Forklift Travel Time by reducing the need to drive deep into the racking system.
• Clearly Defines Inbound & Outbound Zones, allowing forklifts to continuously and efficiently access goods, avoiding delays.
• Quick & Easy Assembly due to a modular racking structure.
• Securely Anchored System, with all components firmly fixed to the warehouse floor, ensuring safety for both goods and workers.

If your business is looking to increase warehouse capacity while maintaining clear and safe product flow, Pallet Flow Racking is a practical solution to consider. Eurorack is ready to conduct site surveys, provide suitable consulting, and design an optimized system that supports efficient and stable long term warehouse operations.



Hotline: +84.938.520.379WhatsApp: +84.938.520.379Get a Quote Now

Operating Principle of Flow Rack System

Flow Racks are designed with a slight incline of 1 to 3 degrees, allowing pallets to slide forward using gravity towards the picking end. This reduces unloading time and streamlines warehouse operations.

• When a pallet is removed, the next pallet automatically moves forward to occupy the empty space.
• This continuous pallet flow ensures efficient inventory rotation and simplifies stock management.

Pallet Flow shelves operate based on gravity

Which Warehouses Should Use Flow Rack Systems?

Flow Rack Systems are an ideal solution for industries requiring high-density storage and efficient inventory turnover. They are best suited for:

• Warehouses storing products with a shelf life of 3 months to 1 year.
• Storage hubs and staging areas for goods awaiting transportation (commonly found in intermediate warehouses).
• Food storage warehouses and other FMCG (Fast-Moving Consumer Goods) industries.
• Cold storage warehouses for frozen food and perishable goods.
• Warehouses operating under the FIFO (First In, First Out) inventory management system.

As one of Vietnam’s leading manufacturers in the pallet racking industry, Eurorack is a trusted partner of major domestic and international corporations, including Nestlé, PepsiCo, Vinamilk, and more.

Eurorack is the leading Pallet Flow racking manufacturing brand in Vietnam

Why Choose Flow Rack Systems from Eurorack?

Superior Quality & Durability

• High-strength steel sourced from Hòa Phát, ensuring exceptional load capacity and durability.
• Extends warehouse racking lifespan up to 20 years.
• Expert engineering team designs customized solutions tailored to your warehouse storage needs, ensuring precision and safety in operation.

Advanced Manufacturing & Direct Supply

• State-of-the-art, automated production facilities spanning 20,000 square meters, maximizing efficiency and reducing lead time.
• ISO 9001:2015-certified racking systems, ensuring top-tier quality control.
• Direct manufacturer-to-customer supply chain, eliminating intermediary costs.

Exclusive Customer Benefits

• Free warehouse survey, design consultation, transportation, and installation support.
• Comprehensive warranty & maintenance policy, covering up to 36 months for Flow Rack systems.

Looking for a reliable Flow Rack supplier?
Contact Eurorack today for a free 3D warehouse simulation, site measurement, and an accurate installation quotation!
